M-330X 溶剂喷绘机

M-330X 溶剂喷绘机
RT00069
M-330X 蛟龙号


内容Item

规格Specification

型号Model

M-330X

喷头Print head

KONICA 512I (30PL)

喷头数量Number of Printhead

4

8

打印宽度Maximum Print Width

3.2M(126inch)

打印速度Print Speed

Draft    草稿模式

110 sqm/hr

190 sqm/hr

Standard标准模式

70 sqm/hr

135 sqm/hr

Ultra    精细模式

55 sqm/hr

105 sqm/hr

颜色Color

CMYK

介质Media

Paper, Advertising Banner, PVC, Mesh Fabrics, Vinyl

纸,灯箱布,PVC,网格布,背胶

最高打印精度Maximum Print quality

720dpi

自动收放布系统Auto Media System

标配Equipped

喷头自动清洗系统

Auto Cleaning System

正压清洗 Positive Pressure Cleaning

防堵闪喷功能Spray in Idel Function

图像格式Image Format

Bitmap, TIFF, Quark Xpress, JPGEG, AI, EPS, PDF

色彩管理Color Management

国际ICC曲线Superior ICC Profile

工作流程Work Flow

RIP后打印或者边RIP边打印

RIP and Print at the same time/Print after RIP

数据传输接口Print Interface

USB2.0

墨水类型Ink Type

Solvent Based Ink 溶剂型墨水

软件Software

Photo Print 10, Revotech Edition

工作站Work Station

Microsoft Windows XP/Windows7

工作环境Operating Environment

220V~(+10%)>15A,50Hz/60Hz

机器尺寸Machine Dimension

480x72x155CM

木箱尺寸

Wooden Case Dimension

489x77x167CM
