HG-330X UV喷绘机

内容Item

规格Specification

型号Model

HG-330X

喷头Print head

KONICA 1024i 6PL

喷头数量

Number of Printhead

4

8

打印宽度

Maximum Print Width

3.2M(126inch)

打印速度Print Speed

Draft    草稿模式

36 sqm/hr

70 sqm/hr

Standard标准模式

25 sqm/hr

50 sqm/hr

Ultra    精细模式

16 sqm/hr

30 sqm/hr

颜色Color

CMYK

介质Media

纸，灯箱布，PVC，网络布，背胶，无涂层卷材，PE，轻型板材

Paper, Advertising Banner, PVC, Mesh Fabrics, Vinyl, PE, Light Boards

最高打印精度Maximum Print quality

2880dpi

自动收放布系统Auto Media System

标配Equipped

自动喷头清洗系统

Auto Cleaning System

正压清洗Positive Pressure Cleaning

防堵闪喷功能Spray in Idel Function

图像格式Image Format

Bitmap, TIFF, Quark Xpress, JPGEG, AI, EPS, PDF

色彩管理Color Management

国际ICC曲线Superior ICC Profile

工作流程Work Flow

先RIP后打印或者是边RIP边打印

RIP and Print at the same time/Print after RIP

数据传输接口Print Interface

USB2.0

墨水类型Ink Type

LED-UV Curing Ink

软件Software

Photo Print 10, REVOTECH Edition

工作站Work Station

Microsoft Windows XP/Windows 7

工作环境Operating Environment

220V~(+10%)>15A,50Hz/60Hz

机器尺寸Machine Dimension

562x102x184CM
